PROFESSIONAL THERMAL IMAGING CAMERA
The Mileseey TR10 is a compact thermal camera designed for quick temperature diagnostics and locating thermal anomalies. It features a clear 2.8" screen and a 192 × 192 px sensor, providing a sharp image with easy-to-interpret details.

The camera operates from -20°C to 550°C and offers a wide 50° × 50° field of view, making it easier to inspect larger areas. A visual alarm is also available and triggers when user-set temperature thresholds are exceeded.

KEY FUNCTIONS

• tracking of maximum and minimum temperatures

• automatic indication of hot and cold spots

• adjustable emissivity setting

• low/high temperature warning (alarm)

• automatic data saving function

• convenient USB-C port for charging and operation

• high-capacity battery providing up to approx. 9 hours of operation (depending on settings)

• wide temperature range: -20 to 550°C

• compliance with standards and certifications incl. CE, FDA, FCC (and others)

TECHNICAL SPECIFICATIONS

• Model: TR10
• Temperature range: -20°C – 550°C (4°F – 1022°F)
• IR resolution: 192 × 192
• Accuracy: ±3°C
• Thermal sensitivity: ≤50 mK
• Display: 2.8”
• Refresh rate: <25 Hz
• Field of view: 50° × 50°
• Focal length: 1.35 mm
• Hot/cold spot alarm: yes
• Color palettes: 8
• Photo format: JPEG
• Power supply: lithium battery (up to approx. 9 h)
• Protection rating: IP54
• Dimensions: 224 × 76 × 91 mm
• Weight: 387 g

COLOR PALETTES — 8 MODES
8 thermal image display modes available:
White hot, Black hot, Iron, Rainbow, Blend, Red hot, Blue hot, Green hot.

THERMAL CAMERA PARTS DESCRIPTION:

1. USB-C charging port
2. LCD screen
3. Button: photo saving
4. Button: “up/down/left/right”
5. Button: “power on/off/back”
6. Settings button
7. Camera lens
8. Image recording / taking photos

DISPLAY INDICATORS DESCRIPTION:

1. Battery level
2. Center temperature
3. Center point / crosshair
4. Maximum temperature and its location
5. Minimum temperature and its location
6. Time
7. Maximum temperature on the side temperature bar
8. Temperature scale bar
9. Minimum temperature on the side temperature bar
10. N: normal range (N changes to H after selecting the high temperature range)
11. Emissivity value (adjustable)
12. Detection distance

PACKAGE CONTENTS:

• TR10 thermal camera

• user manual in English and Polish

• original packaging

• protective case

• USB Type-C cable

Mileseey is a brand specializing in practical measuring and diagnostic devices, including distance meters, laser levels, and thermal imaging cameras. Mileseey products are valued for functionality, clear displays, and a good price-to-performance ratio, making them suitable for both home and professional use.
